Fluke 435 Series II Power Quality and Energy Analyzer.

Volt

Vrms (AC + DC)

Measurement range: 1 to 1000 V phase to neutral
Resolution: 0.01 V
Accuracy: ±0.1% of nominal voltage¹

Vpk

Measurement range: 1 to 1400 Vpk
Resolution: 1 V
Accuracy: 5% of nominal voltage

Voltage Crest Factor (CF)

Measurement range: 1.0 > 2.8
Resolution 0.01
Accuracy: ±5%

Vrms 1/2

Resolution: 0.1 V
Accuracy: ±0.2% of nominal voltage

Amps

i430-Flex 1x

Measurement range: 5 to 6000 A
Resolution: 1 A
Accuracy: ±0.5% ±5 counts

i430-Flex 10x

Measurement range: 0.5 to 600 A
Resolution: 0.1 A
Accuracy: ±0.5% ±5 counts

1mV/A 1x

Measurement range: 5 to 2000 A
Resolution: 1 A
Accuracy: ±0.5% ±5 counts

1mV/A 10x

Measurement range: 0.5 to 200 A (AC only)
Resolution: 0.1 A
Accuracy: ±0.5% ±5 counts

i430-Flex

Measurement range: 8400 Apk
Resolution: 1 Arms
Accuracy: ±5%

1mV/A

Measurement range: 5500 Apk
Resolution: 1 Arms
Accuracy: ±5%
