ALLIED TELESIS AT-x610-24Ts/X-60 24 Port Gigabit Advanced Layer 3 Switch

Category

Network switches

Description

Allied Telesis AT x610-24Ts/X - Switch - L3 - managed - 24 x 10/100/1000 + 4 x combo Gigabit SFP + 2 x SFP+ - rack-mountable

Manufacturer

Allied Telesis

MSRP

$4,000.00

UNSPSC

43222612

Dimensions & Weight / Depth

42 cm

Dimensions & Weight / Height

4.4 cm

Dimensions & Weight / Width

44 cm

Header / Brand

Allied Telesis

Networking / Form Factor

Rack-mountable

Networking / Ports Qty

24

Networking / Type

Switch

Packaged Quantity

1

Depth

42 cm

Height

4.4 cm

Width

44 cm

Humidity Range Operating

5 - 90% (non-condensing)

Humidity Range Storage

5 - 95% (non-condensing)

Max Operating Temperature

40 °C

Max Storage Temperature

70 °C

Min Operating Temperature

0 °C

Min Storage Temperature

-25 °C

Expansion Slots

·         1 (total) / 1 (free) x expansion slot

·         1 (total) / 1 (free) x SD Memory Card

Interfaces

·         24 x 1000Base-T RJ-45

·         1 x console RJ-45 management

·         4 x SFP (mini-GBIC)

·         2 x SFP+

Authentication Method

RADIUS, TACACS+, Extensible Authentication Protocol (EAP)

Capacity

·         RIP routes: up to 5000

·         Virtual interfaces (VLANs): 4096

Compliant Standards

IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.1AX

Device Type

Switch - 24 ports - L3 - managed - stackable

Enclosure Type

Rack-mountable 1U

Encryption Algorithm

DES, Triple DES, RSA, MD5, SHA-1, TLS 1.0, SSL 3.0, SSL 2.0, PEAP, TTLS

Features

Flow control, BOOTP support, ARP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, IPv6 support, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), Network Admissions Control (NAC), Jumbo Frames support, Dynamic ARP Inspection (DAI), STP Root Guard, LLDP support

Flash Memory

64 MB

Jumbo Frame Support

9KB

MAC Address Table Size

32K entries

Max Units In A Stack

8

Performance

·         Switching capacity: 136 Gbps

·         Forwarding performance: 101.2 Mpps

Ports

24 x 10/100/1000 + 4 x combo Gigabit SFP + 2 x SFP+

RAM

512 MB DDR SDRAM

Remote Management Protocol

SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, SSH, CLI

Routing Protocol

RIP-1, RIP-2, ECMP, policy-based routing (PBR)

Subtype

Gigabit Ethernet

Compliant Standards

FCC Class A certified, UL, TUV, cUL, EN 61000-3-2, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, RoHS, UL 60950-1, EN 60950-1, CSA C22.2 No. 60950-1-03, EN 60825-1

Features

Redundant Power System (RPS) connector

Power Device

Internal power supply

Voltage Required

AC 120/230 V (50/60 Hz)
