Robustel R3000-L3P Dual SIM industrial router

Cellular Interface

Standards

GSM/GPRS/EDGE/UMTS/HSPA/FDD LTE

GPRS/EDGE

850/900/1800/1900 MHz

HSPA+

850/900/1900/2100 MHz, DL/UL 21/5.76 Mbps, fallback to 2G

FDD LTE

800/900/1800/2100/2600 MHz, DL/UL 100/50 Mbps, fallback to 3G/2G

EVDO

450 or 800/1900 MHz, Rev A/B

SIM

2 x (3V & 1.8V)

Antenna Interface

SMA Female

Ethernet Interface

Number of Ports

10/100 Mbps, 2 LANs or 1 LAN 1 WAN

Magnet Isolation Protection

1.5KV

WLAN Interface (Optional)

Standards

802.11b/g/n , support AP and Client mode

Frequency Band

2.412 - 2.485 GHz

Security

WEP ,WPA, WPA2

Encryption

64/128AES, TKIP

Antenna Interface

RP-SMA Female

Transmission Power

802.11b: 17dBm, 802.11g/n: 15dBm

Reception Sensibility

1M: -97dBm, 2M: -93dBm, 6M: -91dBm, 11M: -89dBm, 54M: -75dBm, 65M: -72dBm

System

LED Indicators

RUN, PPP, USR, 3 x RSSI

Built-in

Watchdog, Timer

Software

Network protocols

PPP, TCP, UDP, DHCP, ICMP, NAT, DMZ, DDNS, VRRP, HTTP, HTTPs, DNS, ARP, SNTP, Telnet, etc

VPN tunnel

IPSec/OpenVPN/GRE

Firewall

SPI, anti-DoS, Filter, Access Control

Management

Web, SMS, CLI, RobustLink

RobustLink

Centralized M2M management platform

RobustVPN

Cloud VPN Portal

Power Supply and Consumption

Power Supply Interface

3.5mm terminal block with lock

Input Voltage

9 to 26 VDC

Power Consumption

Idle: 100 mA @ 12 V
Data Link: 500 mA (peak) @ 12 V

Physical Characteristics

Housing & Weight

Metal, 300g

Dimension

(L x W x H): 127.5 x 82.5x 29.5 mm

Installation

35mm Din-Rail or wall mounting or desktop

Regulatory and Type Approvals

Approval & Certification

CE, R&TTE, RoHS, WEEE

EMI

EN 55022 (2006/A1: 2007) Class B

EMC

EN 61000-4-2 (ESD) Level 4, EN 61000-4-3 (RS)Level 4
EN 61000-4-4 (EFT) Level 4, EN 61000-4-5 (Surge) Level 3
EN 61000-4-6 (CS) Level 4, EN 61000-4-8 Level 4
