NETEQUALIZER 3000 SERIES DATA SHEET P/N CSE-512

Form Factor

·         14" Mini 1U chassis - supports for maximum motherboard sizes: ATX 12" x 9.6"

Processor Support

·         Single Intel® and AMD processors

Dimensions

Height

·         1.7" (43 mm)

Width

·         16.8" (426 mm)

Depth

·         14" (356 mm)

Gross Weight

·         12.8 lbs (5.81 kg)

Packaging (W x H x L)

·         22" (559 mm) x 6.3" (160 mm) x 20" (508 mm)

Available Color

·         Black

Expansion Slots

·         1x Full-height, Half-length expansion slot(s) (Riser Card Required)

Drive Bays

·         1x 3.5" fixed drive bay

·         SAS or enterprise SATA HDD only recommended

Peripheral Drives

·         Optional 1x Slim DVD-ROM Drive

·         1x slim DVD-ROM drive bay

Front Panel

Button

·         Power On/Off button

·         System Reset button

LED

·         Power status LED

·         HDD activity LED

·         2 Network Activity LEDs

·         Fan Fail/System Over Heat LED

Port

·         2x USB 2.0 Port(s)

Systems Cooling

Fans

·         1x 10cm blower

Operating Environment (System)

Operating Temperature Range

·         5°C - 35°C (41°F - 95°F)

Non-Operating Temperature Range

·         -40°C - 70°C (-40°F - 158°F)

Operating Relative Humidity Range

·         8% - 90% (non-condensing)

Non Operating Relative Humidity Range

·         5% - 95% (non-condensing)

Power Supply

1U 200W Multi-output power supply Gold level w/20pin

Power Efficiency

·         91%

Total Output Power and Input

·         200W with Input 100 - 240Vac

AC Input Frequency

·         50-60Hz

Dimensions (L x W x H)

·         192 x 76 x 40.3 mm

Output Type

·         20pin ATX

-12V

·         Max: 0.5A / Min: 0A

+12V

·         Max: 16A / Min: 0.1A (100Vac - 240Vac)

+5V

·         Max: 8A / Min: 0.1A

+3.3V

·         Max: 8A / Min: 0.1A

+5Vsb

·         Max: 2A / Min: 0A

Certification

·            Gold Certified

Regulatory (Power Supply)

Power Supply Safety / EMC

·         BSMI

·         CCC

·         CE/EMC

·         FCC class B

·         TUV/CB

·         UL/CUL
