ARUBA NETWORKS AP-175P 2x2 Dual Radio Outdoor Access Point

Main Specifications

Product Description

Aruba AP 175P - wireless access point

Device Type

Wireless access point

Form Factor

External - outdoor

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n

Frequency Band

2.4 GHz, 5 GHz

Power Over Ethernet (PoE) Supported

PoE

Dimensions (WxDxH)

10.2 in x 9.4 in x 4.1 in

Weight

7.3 lbs

General

Device Type

Wireless access point

Ruggedized Design

Outdoor

Width

10.2 in

Depth

9.4 in

Height

4.1 in

Weight

7.3 lbs

Networking

Form Factor

External

Connectivity Technology

Wireless

Data Transfer Rate

300 Mbps

Line Coding Format

CCK, 64 QAM, BPSK, QPSK, 16 QAM

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n

Spread Spectrum Method

OFDM, DSSS

Frequency Band

2.4 GHz, 5 GHz

Features

Auto-sensing per device, power over Ethernet (PoE), auto-uplink (auto MDI/MDI-X), MIMO technology, wall mountable

Compliant Standards

IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, Wi-Fi CERTIFIED, IEEE 802.11n, IEEE 802.3at

Expansion / Connectivity

Interfaces

1 x 1000Base-T - RJ-45
4 x antenna - N connector
1 x USB

Miscellaneous

Compliant Standards

VCCI, EN 60950, NOM, IEC 60950, UL 60950, IEC 60529 IP66, CB, EN 300.328, AS/NZS 4771, CCC, MIC, AS/NZS 3548, FCC, KCC, EN 301.893, cTUVus

Power

Power Over Ethernet (PoE) Supported

PoE

Power Consumption Operational

15 Watt

Manufacturer Warranty

Service & Support

1 year warranty

Service & Support Details

Limited warranty - parts and labor - 1 year

Environmental Parameters

Min Operating Temperature

-22 °F

Max Operating Temperature

131 °F

Humidity Range Operating

5 - 95% (non-condensing)
