D-Link DGS-1210-28P 28-Port Gigabit Smart Managed PoE 4xSFP Switch

General Port Standards & Functions

• IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted-pair copper)
• IEEE 802.3z 1000Base-X
• IEEE 802.3az Energy Efficient Ethernet
• IEEE 802.3x Flow Control
• IEEE 802.3af
• IEEE 802.3at
• Auto-negotiation



Number of Ports

• 24 10/100/1000Base-T PoE
• 4 combo 100/1000Base-T/SFP



Network Cables

• UTP Cat. 5, Cat. 5e (100 m max.)



Full/Half Duplex

• Full/half duplex for 10/100 Mbps speeds
• Full duplex for Gigabit speed



Media Interface Exchange

• Auto or configurable MDI/MDIX



Performance

Switching Capacity

• 56 Gbps



Transmission Method

• Store-and-forward



MAC Address Table

• 8K entries



MAC Address Update

• Up to 256 static MAC entries



Maximum 64 bytes packet forwarding rate

• 41.7 Mpps



Packet Buffer Memory

• 512 KB per device



PoE Capable Ports

• Up to 30 W on ports 1 to 24



PoE Power Budget

• 193 W



Physical & Environmental

Power Input

• 100 to 240 V AC 50/60 Hz, internal universal power supply



Maximum Power Consumption

• 263.9 W (PoE on)
• 30.6 W (PoE off)



Standby Power Consumption

• 19.6 W/100 V, 16.6 W/240 V



Fan Quantity

• 2 fans



Acoustics

• High speed: 51,7 dB(A)
• Low speed: 44,9 dB(A)



Heat Dissipation

• 900.36 BTU/hr



Operating Temperature

• -5 to 50°C



Storage Temperature

• -20 to 70°C



Operating Humidity

• 0% to 95% non-condensing



Storage Humidity

• 0% to 95% non-condensing



Dimensions

• 440 x 250 x 44 mm



Weight

• 3.75 kg



Diagnostic LEDs

• Power (per device)
• PoE Max (per device)
• Link/Activity/Speed (per port)
• Power Fail/Power Ok (per PoE port)
