CISCO887VA-K9 Cisco 887 VDSL/ADSL over POTS Multi Mode Router

Rack capacity

1U

LED indicators

Yes

DSL WAN

Yes

Ethernet LAN

Yes

Networking standards

IEEE 802.1D,IEEE 802.1Q,IEEE 802.1x,IEEE 802.3

Ethernet interface type

Fast Ethernet

Cabling technology

10/100Base-T(X)

Ethernet LAN data rates

10,100 Mbit/s

Auto MDI/MDI-X

Yes

Internal modem

No

ADSL2+

Yes

Web-based management

Yes

Quality of Service (QoS) support

Yes

Firmware upgradeable

Yes

Ethernet LAN (RJ-45) ports quantity

4

USB ports quantity

1

USB version

1.1

DC-in jack

Yes

DHCP client

Yes

DHCP server

Yes

Routing protocols

EIGRP,HSRP,RIP-1,RIP-2

Voice codecs

G.711,G.723.1,G.726,G.728,G.729

Security algorithms

3DES,128-bit AES,192-bit AES,256-bit AES,802.1x RADIUS,DES,HTTPS,SSH,SSL/TLS,WPA2

Firewall

Yes

MAC address filtering

Yes

Network address translation (NAT)

Yes

VPN tunnels quantity

20

Built-in processor

Yes

Internal memory

256 MB

Electromagnetic compatibility

47 CFR, CISPR22: 2005, EN300386: V1.3.3: 2005, EN55022: 2006, EN61000-3-2: 2000, EN61000-3-3: 1995, ICES-003, KN 22: 2005, VCCI: V-3/2006.04

Power supply

60 W

Power source type

AC

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Output voltage

12 V

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-20 - 65 °C

Operating relative humidity (H-H)

10 - 85%

Storage relative humidity (H-H)

5 - 95%

Operating altitude

0 - 3000 m

Non-operating altitude

0 - 4570 m
